Constraint on a beam bottom surface not on the neutral axis

Submitted by Yuchi Kang on

Hi!

I have a question regarding the beam deflection. As shown in the pic, the roller constraint is applied on the bottom of the beam(Beam A) rather than neutral axis(Beam B). Could anybody help to provide some information about Beam A hand calculation?

Thanks!

https://files.fm/u/54jwqnru#sign_up

Attachment Size
20181015200115.jpg 51.25 KB
